Separated-Type Precision CNC Auto Feed Band Saw CD-600
The separated-type precision CNC auto feed band saw CD-600 is designed for high-precision, automated aluminum profile cutting and larger material processing. Its separated cutting structure moves the saw blade and material apart after cutting, reducing friction and helping prevent scratches on the finished surface. The direct-drive spindle minimizes mechanical vibration and tool oscillation, supporting smooth, burr-free cuts. CNC automatic feeding enables recyclable material feeding from 10 to 1100 mm, while the welded and annealed machine bed provides structural stability during long-term operation. With spindle accuracy of 0.005 mm and cutting precision of ±0.1 mm, CD-600 is suitable for efficient, repeatable industrial aluminum profile cutting.
5.0
Machine model:
CD-600
Cutting length:
10～1100mm(Recyclable feeding)
Cutting width and height:
W460mm H210mm
Motor power:
7.5KW～15KW
The size of the saw blade:
φ405～φ650
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Why Choose CD-600?
☀ For Large-Size Material Cutting
With a cutting capacity of up to W460 × H210 mm, the CNC band saw machine can accommodate larger aluminum profiles and sections that may exceed the working range of standard profile cutting machines. Its stable material support and clamping help maintain positioning during the cutting process, making it suitable for industrial profiles and larger structural sections.
☀ For Repeatable Production
The CNC automatic feeding system controls material movement according to preset cutting parameters, while the recyclable feeding function supports repeated cutting operations. This reduces the need for continuous manual measurement and feeding, helping manufacturers maintain consistent cutting lengths across multiple workpieces and improve production efficiency.
☀ For Stable Cutting Quality
The direct-drive spindle connects the motor directly to the saw blade, reducing unnecessary mechanical transmission components and helping minimize vibration and tool oscillation. Combined with the rigid machine structure, this configuration supports a more stable cutting path and consistent processing quality during repetitive production.
☀ For Clean Cut Surfaces
The separated-type cutting structure allows the saw blade and material to separate after the cutting operation, reducing unnecessary contact between the blade and the finished section. This helps minimize friction and potential surface damage while supporting smoother, cleaner cut ends and reducing the need for additional finishing.
☀ For Long-Term Industrial Operation
The welded machine bed undergoes heat treatment and annealing to improve structural stability and reduce the effects of internal stress. This provides a more stable foundation for the cutting system during extended operation, helping maintain consistent positioning and cutting performance in demanding industrial production environments.
Intelligent
Precise
Efficient
Stable
Suitable Materials & Production Applications
1.Material Characteristics
The CNC band saw machine is suitable for processing aluminum profiles and larger aluminum sections that require accurate and repeatable length cutting. Its cutting capacity of up to 460 mm in width and 210 mm in height allows it to handle a range of industrial profile sizes. The stable clamping and direct-drive cutting system help maintain material positioning during processing while supporting smooth, clean cut surfaces.
2.Production Requirements
The CD-600 is well suited to production environments requiring repetitive, high-precision, and automated cutting. Its CNC automatic feeding system and recyclable feeding function support continuous processing of multiple workpieces with consistent cutting lengths. It is particularly suitable for medium- to high-volume production, standardized profile processing, and applications where reduced manual feeding and stable cycle-to-cycle performance are important.
application
◆Aluminum Profile Processing
The CNC auto feed saw is suitable for cutting aluminum extruded profiles into accurate lengths for subsequent machining, assembly, and fabrication. Its CNC automatic feeding system supports repeatable cutting operations while reducing manual material handling.
◆Large-Size Aluminum Sections
With a cutting capacity of up to 460 mm in width and 210 mm in height, it is suitable for larger aluminum sections that require stable positioning and precise length cutting.
◆Heat Sink Profiles
CD-600 can be used to cut aluminum heat sink profiles into defined lengths before further machining or assembly. Consistent cutting helps maintain dimensional uniformity for subsequent processing.
◆New Energy Equipment Components
CD-600 CNC bandsaw machine is suitable for cutting aluminum components used in new energy equipment and related industrial applications. Its automated feeding and repeatable cutting process help support consistent component production.
◆Industrial Frames and Housings
For aluminum frames, equipment housings, and other fabricated structures, it provides controlled length cutting for profiles requiring repeatable dimensions and clean cut surfaces.
Technical Parameter
| Machine model | CD 600 |
| Cutting length | 10～1100mm（Recyclable feeding） |
| Cutting width and height | W460mm H210mm |
| Motor power | 7.5KW～15KW |
| The size of the saw blade | φ405～φ650 |
| Motor speed | 3000r/min |
| Accuracy of motor spindle | 0.005mm |
| Cutting precision | ±0.1mm |
| Working air pressure | 0.4～0.8Mpa |
| Working voltage | 380V/50Hz |
| Mechanical size | 2650X1780X1800mm |
| Mechanical weight | 1900kg |
How Does CD-600 Work?
1. Set Cutting Parameters
The operator enters the required cutting length and processing parameters through the CNC control system.
2. Automatic Material Feeding
The CNC feeding system automatically moves the aluminum profile to the preset cutting position. Its recyclable feeding function supports repeated cutting operations.
3. Precise Material Positioning
The profile is positioned according to the programmed cutting length, reducing manual measurement and improving repeatability.
4. Secure Material Clamping
The aluminum profile is firmly clamped before sawing to minimize movement and vibration during cutting.
5. Direct-Drive Precision Cutting
The motor directly drives the saw blade, reducing mechanical transmission and tool oscillation while maintaining stable cutting performance.
6. Separated-Type Cutting
After the cut is completed, the cutting unit and material separate to reduce unnecessary blade contact and friction with the finished workpiece.
7. Repeatable CNC Processing
The system continues the feeding, positioning, clamping, and cutting cycle according to preset parameters, making CD-600 suitable for efficient repetitive production.
FAQ
1
What is recyclable feeding?
Recyclable feeding automatically moves the material forward for repeated cutting, reducing manual repositioning and improving production efficiency.
2
Can the CD-600 be customized for a production line?
Yes. The CD-600 can be configured according to specific material, cutting, and production requirements, with options for customized material handling and processing solutions.
3
Can the CD-600 be integrated into an automated production system?
Yes. Its CNC-controlled feeding and cutting functions allow it to operate as an independent cutting machine or be integrated into a larger automated aluminum processing line.
